Lower Downhole Pressure Well Use Oilfield Sucker Rods Downhole Pumps

Brand Name : Zhongshi

Model Number : RWAC

Certification : API, ISO, QHSE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/P, T/T, Western Union, D/A

Supply Ability : 1000 SETS/MONTH

Delivery Time : 10~15 workdays

Packaging Details : Standard exported packing

Product Name : Sucker rod inserted pump

Application : Oil production by artificial lift technology

Plunger coating : Spray metal

Type : Inserted pump

Material of main parts : 45# steel

Origin : China

Barrel coating : Chrome plated in usual

Hold-down type : Cup

Contact Now

Lower Downhole Pressure Well Use Rod Insert Pumps

Inserted sucker rod pump description:

The Sucker Rod Pumping System (SRP) is considered the most popular artificial lift method worldwide. Its applications cover very low downhole pressure wells, slim holes, multiple completions, high temperature and viscous oil.

There are seven major components for downhole rod pumps: standing and traveling valves, plunger, barrel, seating assembly, pull tube or valve rod (for insert pump), and the fittings that hold the assembled pump together.

Built with bottom or top hold downs

Available with 3 cup seating assembly or mechanical hold down with 443 Brass or 440C SS
Precision barrels up to 40'
Barrels available in Hardened & Honed, Chrome plated, 443 Brass, and Nickel Carbide
Manufactured with spray metal plunger

Technical parameter list:

Model Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in) Sucker rod size
20-125RWAC Ø1.25” +2.1-10.4 0.3-8.0 1.2-9.0 / 2-3/8”

5/8" 3/4"
20-150RWAC Ø1.50” 2-3/8”
25-200RWAC Ø2.00” 2-7/8”
30-250RWAC Ø2.50” 3-1/2


Sucker Rod Pump Features:
1. Proprietary improvements
2. Suitable for lower downhole pressure oil wells
3. It can be designed according to the customer’s requirements.

Lower Downhole Pressure Well Use Oilfield Sucker Rods Downhole Pumps
