Brand Name : Zhongshi
Model Number : RWBM
Certification : API, ISO, QHSE
Place of Origin : China
MOQ : 1 set
Price : Negotiable
Payment Terms : L/C, D/P, T/T, Western Union, D/A
Supply Ability : 1000 SETS/MONTH
Delivery Time : 10~15 workdays
Packaging Details : Standard exported packing
Material : Carbon Steel
Machine type : Petroleum Machinery
Application : Petroleum production
Color : Required
Usage : Oil field
Type : Sucker Rod,Rod Pump
API 11AX Oilfield Rod Pump downhole pump with chrome plated pump barrel
Product description
Sucker rod pump is also called insert pump,the main feature is this type pump has two working barrels,the upper is the outer working barrel which are equipment with vertebral body seat and clamp spring,put the outer working barrel into tubing with the well first,then connect the inner working barrel which is equipment liner and piston in the lower end of the sucker rod pump, after that put it in the outer barrel, and fixed by a circlip.
Feature
1. Rod pump can be pulled out from the well directly.
2. Reduce the cost of pumping test.
3.Well inspection and workover is convenient.
4. Suitable for deeper well.
Technical Specifications
Type | Major technical data | |||||
Diameter(mm) | Barrel Length (m) | Stroke Range (m) | Length of Extension Pub Joint(m) | Thread for Tubing(in) | Connecting sucker rod | |
Rod pumps | 31.8 | 2.1 3.0 3.3 3.6 3.9 4.2 4.5 4.8 5.7 6.0 6.6 7.3 9.1 | 1.5-6 | 0.3 0.6 0.9 | 2 3/8 | CYG16 |
38.1 | 2 7/8 | CYG19 | ||||
44.45 | 2 7/8 | CYG19 | ||||
Tubing pump | 31.8 | 1.5-7.8 | 0.3 0.6 0.9 | 2 3/8 | CYG16 | |
38.1 | 2 7/8 | CYG16 | ||||
44.45 | 2 7/8 | CYG16 | ||||
57.15 | 2 7/8 | CYG19 | ||||
69.85 | 2 7/8 3 1/2 | CYG22 | ||||
82.55 | 3 1/2 | CYG25 | ||||
95.25 | 3 1/2 | CYG25 |
Pictures
![]() |
API 11AX Oilfield Rod Pump Downhole Pump With Chrome Plated Pump Barrel Images |
